ARTIKEL1 - MX-2402 24IN CLINICAL REVIEW
ARTIKEL2 - DISPLAY FHD 1920X1080 300CD/QM 2
Daugialypė terpė - garsiakalbių skaičius - 2
Daugialypė terpė - RMS vardinė galia - 4 W
Daugialypė terpė - Įmontuota kamera - Ne
Daugialypė terpė - įmontuotas (-i) garsiakalbis (-iai) - Taip
Dizainas - Produkto spalva - Balta
Dizainas - Rinkos pozicionavimas - Medicinos
EANCode - 4710739594775
Ekranas - atsako laikas - 5 ms
Ekranas - ekrano forma - Flat
Ekranas - ekrano ryškumas (tipinis) - 250 cd/m²
Ekranas - Ekrano skiriamoji geba - 1920 x 1080 pikselių
Ekranas - Ekrano technologija - LCD
Ekranas - Ekrano įstrižainė - 60,5 cm (23,8")
Ekranas - HD tipo - "Full HD
Ekranas - jutiklinis ekranas - Ne
Ekranas - Kontrasto santykis (dinaminis) - 20000000:1
Ekranas - kontrasto santykis (tipinis) - 1000:1
Ekranas - NTSC aprėptis (tipinė) - 72%
Ekranas - Palaikomos grafikos skiriamosios gebos - 1920 x 1080 (HD 1080)
Ekranas - Paviršiaus kietumas - 9H
Ekranas - Pikselių žingsnis - 0.274 x 0.274 mm
Ekranas - Prigimtinis kraštinių santykis - 16:9
Ekranas - Rodyti spalvų skaičių - 16,7 milijono spalvų
Ekranas - Skaitmeninis horizontalusis dažnis - 24 - 83 kHz
Ekranas - Skaitmeninis vertikalusis dažnis - 50 - 75 Hz
Ekranas - skydelio tipas - VA
Ekranas - Spalvų gamos standartas - NTSC
Ekranas - Žiūrėjimo kampas, horizontalus - 178°
Ekranas - Žiūrėjimo kampas, vertikalus - 178°
Eksploatavimo sąlygos - Darbinė santykinė drėgmė (H-H) - 10 - 90%
Eksploatavimo sąlygos - Darbinė temperatūra (T-T) - 0 - 40 °C
Eksploatavimo sąlygos - Laikymo temperatūra (T-T) - -20 - 60 °C
Eksploatavimo sąlygos - Sandėliavimo santykinė drėgmė (H-H) - 5 - 95%
Energija - Europos gaminių registro energijos vartojimo efektyvumo ženklinimo (EPREL) kodas - 670707
Ergonomika - aukščio reguliavimas - Ne
Ergonomika - Kabelio užrakto lizdas - Taip
Ergonomika - Kabelio užrakto lizdo tipas - Kensingtonas
Ergonomika - pakreipimo kampo diapazonas - 3 - 21°
Ergonomika - pakreipimo reguliavimas - Taip
Ergonomika - skydelio montavimo sąsaja - 75 x 75,100 x 100 mm
Ergonomika - VESA tvirtinimas - Taip
Galia - energijos sąnaudos (SDR) per 1000 valandų - 18 kWh
Galia - Energijos vartojimo efektyvumo klasė (SDR) - E
GarantijaInformacija -
GRUPPE1 - Medicinos įranga
GRUPPE2 - Medical Display
GTIN - 4710739594775
Hoehe - 0
HSTNUMBER - MX2420A1E0100
Kategorija - Kompiuterių monitoriai
Kitos funkcijos - Atitikties sertifikatai - RoHS, Žemos įtampos direktyva (LVD), UKCA, WEEE, CE, REACH
Logistikos duomenys - Suderintos sistemos (HS) kodas - 85285210
LongDesc - The MX-24 is a 24-inch DICOM monitor featuring Full HD 1080p resolution, low-voltage medical power supply with IEC / EN 60601-1 certified. Compatible with DICOM Part 14 standard, it ensures accurate and excellent medical image quality, colour reproduction, and image contrast. Equipped with NeoV™ Optical Hard Glass, the MX-24 withstands alcohol and other commonly used cleaning solutions, allowing medical professionals to sanitize it easily.EASY CLEAN AND ROBUST PROTECTIONThe special design of NeoV Optical Hard Glass and white metal casing prevent dust and waterproof for easy clean and robust protection.DICOM PART 14 CALIBRATIONDICOM Part 14 calibration corrects gamma and luminance to achieve the smooth grayscale for the accurate and consistent appearance of clinical data and other medical images.MEDICAL-GRADE POWER SUPPLY WITH EN/IEC60601-1 CERTIFIEDLow-voltage medical power supply with IEC / EN 60601-1 certified to ensure safety, performance, and reliable operation in any professional medical environment.PIP/PBP SUPPORTThis 24-Inch DICOM monitor enhances work efficiency with PiP/PbP support for multitasking.
LongProductName - 23.8" VA, FHD 1920 x 1080, 5 ms, 250 cd/m², 20000000:1 (DCR), 16.7M, VGA, DVI-D, HDMI, DP 1.2
LongSummaryDescription - AG Neovo MX-24. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: White
Maitinimas - Energijos suvartojimas (budėjimo režimas) - 0.5 W
Maitinimas - energijos suvartojimas (išjungta) - 0.3 W
Maitinimas - Energijos suvartojimas (tipinis) - 18 W
Maitinimas - Energijos vartojimo efektyvumo skalė - Nuo A iki G
Maitinimas - Maitinimo šaltinio tipas - Išorinis
MANUFACTURER - AG NEOVO TECHNOLOGIJA
Našumas - "AMD FreeSync - Ne
Našumas - NVIDIA G-SYNC - Ne
Pakuotės duomenys - Pakuotės aukštis - 517 mm
Pakuotės duomenys - Pakuotės gylis - 249 mm
Pakuotės duomenys - Pakuotės plotis - 672 mm
Pakuotės duomenys - Pakuotės svoris - 10.9 kg
Pakuotės turinys - greitasis pradžios vadovas - Taip
Pakuotės turinys - Pridedamas maitinimo adapteris - Taip
Pakuotės turinys - Įtraukti kabeliai - AC, garso (3,5 mm), VGA
Pavadinimas - AG Neovo MX-24 computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LCD White
Platus - 0
Prekės ženklas - AG Neovo
Prekės ženklo dalies kodas - MX24B0A1E0100
Prievadai ir sąsajos - DisplayPorts kiekis - 1
Prievadai ir sąsajos - DVI-D prievadų kiekis - 1
Prievadai ir sąsajos - DVI prievadas - Taip
Prievadai ir sąsajos - Garso įvestis - Taip
Prievadai ir sąsajos - HDMI - Taip
Prievadai ir sąsajos - HDMI prievadų kiekis - 1
Prievadai ir sąsajos - HDMI versija - 1.4
Prievadai ir sąsajos - VGA (D-Sub) prievadų kiekis - 1
Prievadai ir sąsajos - Įmontuotas USB šakotuvas - Ne
Produkto pavadinimas - MX-24
ShortSummaryDescription - AG Neovo MX-24, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LCD, 5 ms, White
Skolinimas - 0
Starling - N
Stck_Kart - 0
Stck_Pal - 0
Svoris - 0
Svoris ir matmenys - Aukštis (be stovo) - 352.6 mm
Svoris ir matmenys - Aukštis (su stovu) - 392.8 mm
Svoris ir matmenys - Gylis (be stovo) - 56.2 mm
Svoris ir matmenys - Gylis (su stovu) - 196 mm
Svoris ir matmenys - Plotis (be stovo) - 562.4 mm
Svoris ir matmenys - Plotis (su stovu) - 562.4 mm
Svoris ir matmenys - Svoris (be stovo) - 7 kg
Svoris ir matmenys - Svoris (su stovu) - 7.8 kg
URL - https://nl.agneovo.com/nl/content/mx-series_w.asp
ARTIKEL1 - MX-2402 24IN CLINICAL REVIEW
ARTIKEL2 - DISPLAY FHD 1920X1080 300CD/QM 2
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Design - Product colour - White
Design - Market positioning - Medical
EANCode - 4710739594775
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Display brightness (typical) - 250 cd/m²
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - Display diagonal - 60.5 cm (23.8")
Display - HD type - Full HD
Display - Touchscreen - No
Display - Contrast ratio (dynamic) - 20000000:1
Display - Contrast ratio (typical) - 1000:1
Display - NTSC coverage (typical) - 72%
Display - Supported graphics resolutions - 1920 x 1080 (HD 1080)
Display - Surface hardness - 9H
Display - Pixel pitch - 0.274 x 0.274 mm
Display - Native aspect ratio - 16:9
Display - Display number of colours - 16.7 million colours
Display - Digital horizontal frequency - 24 - 83 kHz
Display - Digital vertical frequency - 50 - 75 Hz
Display - Panel type - VA
Display - Colour gamut standard - NTSC
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Power - European Product Registry for Energy Labelling (EPREL) code - 670707
Ergonomics - Height adjustment - No
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Tilt angle range - 3 - 21°
Ergonomics - Tilt adjustment - Yes
Ergonomics - Panel mounting interface - 75 x 75,100 x 100 mm
Ergonomics - VESA mounting - Yes
Power - Energy consumption (SDR) per 1000 hours - 18 kWh
Power - Energy efficiency class (SDR) - E
WarrantyInfo -
GRUPPE1 - Medical Equipment
GRUPPE2 - Medical Display
GTIN - 4710739594775
Hoehe - 0
HSTNUMMER - MX2420A1E0100
Category - Computer Monitors
Other features - Compliance certificates - RoHS, Low Voltage Directive (LVD), UKCA, WEEE, CE, REACH
Logistics data - Harmonized System (HS) code - 85285210
LongDesc - The MX-24 is a 24-inch DICOM monitor featuring Full HD 1080p resolution, low-voltage medical power supply with IEC / EN 60601-1 certified. Compatible with DICOM Part 14 standard, it ensures accurate and excellent medical image quality, colour reproduction, and image contrast. Equipped with NeoV™ Optical Hard Glass, the MX-24 withstands alcohol and other commonly used cleaning solutions, allowing medical professionals to sanitize it easily.EASY CLEAN AND ROBUST PROTECTIONThe special design of NeoV Optical Hard Glass and white metal casing prevent dust and waterproof for easy clean and robust protection.DICOM PART 14 CALIBRATIONDICOM Part 14 calibration corrects gamma and luminance to achieve the smooth grayscale for the accurate and consistent appearance of clinical data and other medical images.MEDICAL-GRADE POWER SUPPLY WITH EN/IEC60601-1 CERTIFIEDLow-voltage medical power supply with IEC / EN 60601-1 certified to ensure safety, performance, and reliable operation in any professional medical environment.PIP/PBP SUPPORTThis 24-Inch DICOM monitor enhances work efficiency with PiP/PbP support for multitasking.
LongProductName - 23.8" VA, FHD 1920 x 1080, 5 ms, 250 cd/m², 20000000:1 (DCR), 16.7M, VGA, DVI-D, HDMI, DP 1.2
LongSummaryDescription - AG Neovo MX-24. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: White
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (off) - 0.3 W
Power - Power consumption (typical) - 18 W
Power - Energy efficiency scale - A to G
Power - Power supply type - External
HERSTELLER - AG NEOVO TECHNOLOGY
Performance - AMD FreeSync - No
Performance - NVIDIA G-SYNC - No
Packaging data - Package height - 517 mm
Packaging data - Package depth - 249 mm
Packaging data - Package width - 672 mm
Packaging data - Package weight - 10.9 kg
Packaging content - Quick start guide - Yes
Packaging content - Power adapter included - Yes
Packaging content - Cables included - AC, Audio (3.5mm), VGA
Title - AG Neovo MX-24 computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LCD White
Breite - 0
Brand - AG Neovo
BrandPartCode - MX24B0A1E0100
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - DVI port - Yes
Ports & interfaces - Audio input - Yes
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Ports & interfaces - Built-in USB hub - No
ProductName - MX-24
ShortSummaryDescription - AG Neovo MX-24, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LCD, 5 ms, White
Laenge - 0
Storno - N
Stck_Kart - 0
Stck_Pal - 0
Gewicht - 0
Weight & dimensions - Height (without stand) - 352.6 mm
Weight & dimensions - Height (with stand) - 392.8 mm
Weight & dimensions - Depth (without stand) - 56.2 mm
Weight & dimensions - Depth (with stand) - 196 mm
Weight & dimensions - Width (without stand) - 562.4 mm
Weight & dimensions - Width (with stand) - 562.4 mm
Weight & dimensions - Weight (without stand) - 7 kg
Weight & dimensions - Weight (with stand) - 7.8 kg
URL - https://nl.agneovo.com/nl/content/mx-series_w.asp
